ETHOS 5040
5040 Auto Ranging Digital Multimeter
Auto select requires no rotary dial selection, place test leads on point of contact and the tester automatically detects which value to display
AC/DC voltage measurement ranges 4V - 600V auto ranging
AC/DC current measurement ranges 40mA - 10A auto ranging
Resistance measurement ranges 400Ω - 40MΩ auto ranging
Frequency, capacitance, duty cyle an diode tests
Audible continuity test
Data hold
Backlight
Auto power off
| Ac Current Measurement | 10A |
| Ac Voltage Measurement | 600V AC |
| Auto Power Down | Yes |
| Auto Ranging | Yes |
| Battery Level Indicator | Yes |
| Battery Size | PP3 |
| Battery Type | Alkaline |
| Capacitance Measurement | 100µF |
| Colour | Black/Yellow |
| Continuity Check | Yes |
| Data Hold | Yes |
| Dc Current Measurement | 10A DC |
| Dc Voltage Measurement | 600V DC |
| Depth | 40mm |
| Dimensions | (H)177 mm x (W)92 mm x (D)40 mm |
| Display Count | 4000 |
| Display Type | LCD |
| Frequency Measurement | 500 kHz |
| Fused | Yes |
| Guarantee | 1 Year |
| Height | 177mm |
| Logistics Partner | NONE |
| Number Of Batteries | 1 |
| Obsolete Iso | 2021-05-26 |
| Packaging Types | Each |
| Product Range | Ethos Multimeters |
| Resistance Measurement | 40 MΩ |
| Safety Range | CAT IV 300V, CAT III 600V |
| Similar Stock | No |
| Supplied With | Red / Black Test Leads and 1 x 9V Battery |
| Type | Professional Digital Multimeter |
| Unspsc V13 | 41113630 |
| Unspsc V18 | 41113630 |
| Unspsc V22 | 41113630 |
| Unspsc V24 | 41113630 |
| Weight | 0.281kg |
| Width | 92mm |
