ETHOS 5040
5040 Auto Ranging Digital Multimeter

Auto select requires no rotary dial selection, place test leads on point of contact and the tester automatically detects which value to display

AC/DC voltage measurement ranges 4V - 600V auto ranging

AC/DC current measurement ranges 40mA - 10A auto ranging

Resistance measurement ranges 400Ω - 40MΩ auto ranging

Frequency, capacitance, duty cyle an diode tests

Audible continuity test

Data hold

Backlight

Auto power off


Ac Current Measurement10A
Ac Voltage Measurement600V AC
Auto Power DownYes
Auto RangingYes
Battery Level IndicatorYes
Battery SizePP3
Battery TypeAlkaline
Capacitance Measurement100µF
ColourBlack/Yellow
Continuity CheckYes
Data HoldYes
Dc Current Measurement10A DC
Dc Voltage Measurement600V DC
Depth40mm
Dimensions(H)177 mm x (W)92 mm x (D)40 mm
Display Count4000
Display TypeLCD
Frequency Measurement500 kHz
FusedYes
Guarantee1 Year
Height177mm
Number Of Batteries1
Obsolete Iso2021-05-26
Packaging TypesEach
Product RangeEthos Multimeters
Resistance Measurement40MΩ
Safety RangeCAT IV 300V, CAT III 600V
Supplied WithRed / Black Test Leads and 1 x 9V Battery
TypeProfessional Digital Multimeter
Unspsc41113630
Weight0.281kg
Width92mm
